20m (66ft) OS2 SC UPC to SC UPC Duplex LSZH 2.0mm Fiber Optic Patch Cable

Click to open expanded view

20m (66ft) OS2 SC UPC to SC UPC Duplex LSZH 2.0mm Fiber Optic Patch Cable

Global Local Service

Lifetime Technical Support

20m (66ft) SC UPC to SC UPC Duplex OS2 Single Mode LSZH 2.0mm Fiber Optic Patch Cable

#35271

Model: S2SCUD

Sold: 98

In Stock: Available

$ 6.60

Item Spotlights

LSZH Flame-retardant Jacket
Grade A Precision Zirconia Ferrule Connectors Ensure Low Loss
Easy Polarity Management with Duplex Clips
G.657.A1 Bend Insensitive Fiber & 10mm Min. Bend Radius
Optical Testing Ensures Network Performance
Meet TIA-604 (FOCIS) Standard
3 Years Warranty, Lifetime After-sales Technical Support

20m (66ft) OS2 SC UPC to SC UPC Duplex LSZH 2.0mm Fiber Optic Patch Cable

20m (66ft) SC UPC to SC UPC Duplex OS2 Single Mode LSZH 2.0mm Fiber Optic Patch Cable

NADDOD

NADDOD

Free Worldwide Shipping on Orders over $ 99

Specifications

Product Highlights

Resources

Specifications

Product Highlights

Resources

Specifications

Connector Type

SC UPC to SC UPC

Fiber Grade

G.657.A/G.652.D

Fiber Mode

OS2 9/125μm

Wavelength

1310/1550nm

Insertion Loss

≤0.3dB

Return Loss

≥50dB

Min. Bend Radius(Fiber Core)

10mm

Min. Bend Radius(Fiber Cable)

10/5D (Dynamic/Static)

Attenuation at 1310 nm

0.36 dB/km

Attenuation at 1550 nm

0.22 dB/km

Fiber Count

Duplex

Cable Diameter

2.0mm

Cable Jacket

LSZH

Polarity

A (Tx) to B (Rx)

Operating Temperature

-20~70°C

Storage Temperature

-40~80°C

Compliance

TIA-604 (FOCIS)

Customization

NADDOD

Product Highlights

Resources

Fiber Patch Cable Datasheet

Quality Certification

ISO140012015

ISO 90012015

ISO450012018

FDA

FCC

RoHS

TUV-Mark

WEEE
