OM4 1m (3ft) MPO Female to 4 LC UPC 8 Fibers Type B Elite Breakout Cable

Click to open expanded view

OM4 1m (3ft) MPO Female to 4 LC UPC 8 Fibers Type B Elite Breakout Cable

Global Local Service

Lifetime Technical Support

1m (3ft) MPO Female to 4 LC UPC Duplex 8 Fibers Type B LSZH Magenta OM4 50/125 Multimode Elite Breakout Cable 3mm

#34393

Model: M4MPOULCU8FB

Sold: 0

In Stock: Available

$ 51.50

Item Spotlights

Optimal 0.15dB Typ. IL with MPO Connector
7.5mm Min. Bend Radius Corning ClearCurve® Fiber
OFNP (Plenum) Fire Rating
IEC-61754-7 and TIA-604-5 (FOCIS-5)
Aggregates 10G/25G Ports to 40G/100G Ports
30-Day Return, 1-Year Warranty, Lifetime After-sales Technical Support

OM4 1m (3ft) MPO Female to 4 LC UPC 8 Fibers Type B Elite Breakout Cable

1m (3ft) MPO Female to 4 LC UPC Duplex 8 Fibers Type B LSZH Magenta OM4 50/125 Multimode Elite Breakout Cable 3mm

NADDOD

NADDOD

Free Worldwide Shipping on Orders over $ 99

Specifications

Product Highlights

Resources

Specifications

Product Highlights

Resources

Specifications

Connector A

MPO Female (Pinless)

Connector B

LC UPC Duplex

Fiber Mode

OM4 50/125μm

Wavelength

850/1300nm

MTP Connector IL

0.35dB Max (0.15dB Typ.)

LC Connector IL

≤0.2dB

MTP Connector RL

≥20dB

LC Connector RL

≥30dB

Attenuation at 850nm

≤2.3dB/km

Attenuation at 1300nm

≤2.3dB/km

Cable Jacket

LSZH

Fiber Count

8 Fibers

Jacket OD

3.0mm

Fan-Out Diameter

2.0mm

Installation Tensile Load

66N

Tensile Strength (Long/Short Term)

80/240N

Storage Temperature

-40 to 85°C (-40 to 185℉)

Operating Temperature

-10 to 70°C (14 to 158℉)

Certification

IEC-61754-7 and TIA-604-5 (FOCIS-5)

Polarity

Type B

Customization
