What is the difference between QSFP-DD 400G ZR and ZR+?

QSFP-DD 400G ZR and ZR+ coherent optical modules have obvious differences in transmission distance, module specifications, power consumption, modulation format and application scenarios, etc. QSFP-DD 400G ZR+ has a longer transmission distance, more advanced modulation and coding technology and stronger digital signal processing capability, which provides a longer transmission capability and is suitable for ultra-long-distance data center interconnection.

What kind of networks can it be used in?

QSFP-DD 400G ZR and ZR+ optical modules can be used in a variety of network topologies, including Point to Point, Star and Ring networks.

400GBASE-ZR DCO QSFP-DD DWDM Tunable Coherent 1528.77~1567.13nm 120km SMF Module for Arista

Click to open expanded view

Global Local Service

Lifetime Technical Support

Arista QDD-400G-ZR Compatible 400GBASE DCO QSFP-DD DWDM Tunable Coherent 120km DDM/DOM Duplex LC SMF Optical Transceiver Module

Name: Arista QDD-400G-ZR Compatible 400GBASE DCO QSFP-DD DWDM Tunable Coherent 120km DDM/DOM Duplex LC SMF Optical Transceiver Module
Brand: Naddod
SKU: 102227
Price: 5699.00 USD
Availability: InStock
Rating: 5.0 (18 reviews)

#102227

Model: QDD-400G-ZR

Sold: 6

In Stock: Available

$ 5699.00

Transceiver Type:

QDD-400G-ZR

QDD-400G-ZR

Brand:

Cisco

Arista

Nokia

Generic

Cisco

Juniper

Arista

Nokia

Item Spotlights

Line Modulation format 400G DP-16QAM
Ideal for Edge DCI (Data Center Interconnect).
Max Power Consumption ≤18W.
C-band tunable to 100GHz or 75GHz grids
Provides a reach up to 120km point-to-point.
Compliant with Hot Pluggable QSFP-DD MSA, OIF-400ZR, OIF-CMIS-05.2, IEEE Std 802.3 Standard.
Class1/1M Standard Product, Compliant with RoHS Environmental Protection Standards (Lead-Free).
DDM(Digital Diagnostic Monitoring) Supported.
30-Day Free Return, 1-Year Free Replacement, 3-Year Warranty, Lifetime After-sales Technical Support.

Arista QDD-400G-ZR Compatible 400GBASE DCO QSFP-DD DWDM Tunable Coherent 120km DDM/DOM Duplex LC SMF Optical Transceiver Module

Free Worldwide Shipping on Orders over $ 99

Specifications

Questions & Answers

Resources

Specifications

Questions & Answers

Resources

Description

Arista QDD-400G-ZR Compatible 400G DCO QSFP-DD DWDM Tunable Coherent 120km DDM/DOM Duplex LC SMF Optical Transceiver Module (SMF, Coherent, LC, DOM, ZR)

NADDOD QDD-400G-ZR is a C-Band optical frequency tunable coherent optical module, combines 7nm coherent DSP ASIC functionality with best in class ultra-narrow line-width tunable lasers, high speed modulators and high responsively coherent receivers to deliver high performance at 400G DP-16QAM modulation formats. The 400G QSFP-DD ZR is deigned to 400G 120Km DCI DWDM applications without inline chromatic dispersion compensation.

Specifications

Form Factor

QSFP-DD

Distance

120km

Wavelength

1528.77~1567.13nm

Connector

Duplex LC

Power Consumption

≤18W

Modulation format

DP-16QAM

FEC

C-FEC

Media

SMF

Channel Range (Tunable)

191.3 to 196.1 THz

Channel Grid

100GHz & 75GHz

Case Temperature(℃)

0 to 75°C (32 to 167°F)

Protocol

OIF-400ZR-02.0, OIF-CMIS-05.2, OIF-C-CMIS-01.2, QSFP-DD-Hardware-Rev6.3, IEEE Std 802.3-2018

Questions & Answers

Ask a Question

What are the features of Coherent Optical Module?

The coherent optical module adopts coherent detection technology, which can accurately measure the phase and amplitude of the received optical signals, thus improving the reception sensitivity and reducing the BER, and has the characteristics of high sensitivity, high bandwidth, long-distance transmission, etc. It is suitable for large-capacity data transmission.

What is the transmission distance of QSFP-DD 400G ZR?

Maximum distance is up to 120km.

What are the rate types supported by the QSFP-DD 400G ZR Optical Module?

It supports rates of 400GbE or 4x100GbE.
